ComponentB8 control arms

Bilstein 51-353094 B8 Pro Control Arms Control Arm Kit

Sold each

Call (780) 473-2424

We reply to price requests within one business day.

Will it fit your vehicle?

Want it installed?Eskimo Auto Repair installs Bilstein suspension in Edmonton.

Country of origin: United States
Box: Ships in Bilstein's own box (about 60 × 35 × 15 cm, 9.5 kg)

100% genuine Bilstein, from authorized North American distribution.

Fitment

162 vehicles, newest years first

Vehicle	Years	Submodels	Position	Drive / body / engine	Notes
Dodge Ram 1500	Years	2009–2010	Submodels	TRX4	Position	Front upper	Drive / body / engine	All	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Dodge Ram 1500	Years	2009–2010	Submodels	Laramie, SLT, ST, Sport	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2026	Submodels	Big Horn, Express, Laramie, Lone Star, Rebel, Tradesman, Warlock	Position	Front upper	Drive / body / engine	All	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2025	Submodels	Big Horn, Laramie, Lone Star, Rebel, Tradesman, Tradesman HFE, Warlock	Position	Front upper	Drive / body / engine	All	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2022–2024	Submodels	Big Horn, HFE, Laramie, Limited Longhorn, Lone Star, Rebel, Tradesman	Position	Front upper	Drive / body / engine	All	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2021	Submodels	Big Horn, HFE, Laramie, Laramie Longhorn, Limited Longhorn, Lone Star, Longhorn, Rebel, Tradesman	Position	Front upper	Drive / body / engine	All	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2019–2020	Submodels	Big Horn, HFE, Laramie, Laramie Longhorn, Lone Star, Rebel, Tradesman	Position	Front upper	Drive / body / engine	All	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2016–2018	Submodels	Big Horn, Express, Laramie, Laramie Longhorn, Lone Star, SLT, Sport, Tradesman	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2016	Submodels	Outdoorsman	Position	Front upper	Drive / body / engine	All	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2015	Submodels	Big Horn, Express, Laramie, Laramie Longhorn, Lone Star, Outdoorsman, SLT, Sport, Tradesman	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2014	Submodels	Big Horn, Express, Laramie, Laramie Limited, Laramie Longhorn, Lone Star, Outdoorsman, SLT, Sport, Tradesman	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2013	Submodels	Big Horn, Express, Laramie, Laramie Longhorn, Outdoorsman, SLT, Sport, Tradesman	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2012	Submodels	Big Horn, Express, Laramie, Laramie Longhorn, Outdoorsman, SLT, ST, Sport, Tradesman	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500	Years	2011	Submodels	Big Horn, Laramie, Laramie Longhorn, Outdoorsman, SLT, ST, Sport, Tradesman	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500 Classic	Years	2024	Submodels	Tradesman, Warlock	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500 Classic	Years	2020–2023	Submodels	Express, SLT, Tradesman, Warlock	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies
Ram 1500 Classic	Years	2019	Submodels	Big Horn, Express, Laramie, Lone Star, SLT, Tradesman, Warlock	Position	Front upper	Drive / body / engine	4WD	Notes	Compatible with direct fit lift shocks or coilovers only Compatible with OEM spindles only Not for use with lift spacers Requires wheels with maximum 4.75" backspacing Check which applies

Specifications

As Bilstein publishes them.

Finish: Powder-Coated Black
Kit Contents: Pair of upper control arms with installed ball joints and bushings, mounting hardware, instructions
Arm Design: Tubular
Arm Material: 4130 Chromoly Tubing
Arm Inner Pivot Type: Maintenance free bushings - composite lined double bonded urethane with free spinning inner sleeve
Arm Outer Pivot Type: High strength 4140 steel ball joints with increased articulation

Installation & warranty

Bilstein installation instructions (PDF)

Limited Lifetime Warranty · Warranty terms (PDF)

100% genuine Bilstein, from authorized North American distribution.

BILSTEIN is a trademark of thyssenkrupp Bilstein GmbH. Eskimo is an independent retailer.
