BestB16 coilovers

Bilstein 48-275071 B16 PSS10 Suspension Kit

Sold each

Call (780) 473-2424

We reply to price requests within one business day.

Will it fit your vehicle?

Want it installed?Eskimo Auto Repair installs Bilstein suspension in Edmonton.

Country of origin: Germany
Box: Ships in Bilstein's own box (about 60 × 30 × 30 cm, 24.6 kg)

100% genuine Bilstein, from authorized North American distribution.

Fitment

54 vehicles, newest years first

Vehicle	Years	Submodels	Position	Drive / body / engine	Notes
Audi A4	Years	2017–2020	Submodels	Premium, Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi A4 Quattro (AWD)	Years	2019	Submodels	Premium, Premium Plus, Prestige, Ultra sport	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi A4 Quattro (AWD)	Years	2017–2018	Submodels	Premium, Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi A5 Quattro (AWD)	Years	2018–2021	Submodels	Premium, Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi A5 Sportback	Years	2018–2019	Submodels	Premium, Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi S4	Years	2019	Submodels	Premium, Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi S4	Years	2018	Submodels	Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi S5	Years	2019	Submodels	Premium, Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi S5	Years	2018	Submodels	Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies
Audi S5 Sportback	Years	2018–2019	Submodels	Premium Plus, Prestige	Position	Front and rear	Drive / body / engine	All	Notes	Front Lowered Height: 30-50mm, up to 1260kg Axle Load Rear Lowered Height: 30-50mm, up to 1250kg Axle Load 49mm Outside Strut Diameter Without Electronic Suspension Check which applies

Specifications

As Bilstein publishes them.

Internal Design: Monotube
Finish: Dampers: Zinc Front Yellow Rear/Springs: Blue
Front Main Spring Rate (lbs/in): 486
Front Main Spring Type: Progressive
Rear Main Spring Rate (lbs/in): 543
Rear Main Spring Type: Progressive
Front Tender Spring Rate (lbs/in): N/A
Rear Tender Spring Rate (lbs/in): N/A
Spanner Wrench Set: E4-XS1-Z001A00

Installation & warranty

Bilstein installation instructions (PDF) Bilstein general installation instructions (PDF)

Limited 5-Year Warranty · Warranty terms (PDF)

100% genuine Bilstein, from authorized North American distribution.
