Bilstein 45-248573 B4 OE Replacement Air Air Suspension Strut
Sold each · 2 per axle
Call (780) 473-2424
We reply to price requests within one business day.
Will it fit your vehicle?
- Replaces OE
Audi 4G0 616 039 AB, Audi 4G0 616 039 AD, Audi 4G0 616 039 AL, Audi 4G0 616 039 AQ, Audi 4H0 616 039 AA, Audi 4H0 616 039 AC and 6 more
Audi 4H0 616 039 AD, Audi 4H0 616 039 AE, Audi 4H0 616 039 AK, Audi 4H0 616 039 AP, Audi 4H0 616 039 AQ, Audi 4H0 616 039 AS
- Country of origin
- Germany
- Box
- Ships in Bilstein's own box (about 61 × 22 × 22 cm, 9.2 kg)
100% genuine Bilstein, from authorized North American distribution.
Fitment
40 vehicles, newest years first
| Vehicle | Years | Submodels | Position | Drive / body / engine | Notes |
|---|---|---|---|---|---|
| Audi A8 Quattro (AWD) | 2017–2018 | L, L Sport | Front | All |
|
| Audi A8 Quattro (AWD) | 2016 | L, L TDI, L W12 | Front | All |
|
| Audi A8 Quattro (AWD) | 2014–2015 | Base, L, L TDI, L W12 | Front | All |
|
| Audi A8 Quattro (AWD) | 2012–2013 | Base, L, L W12 | Front | All |
|
| Audi A8 Quattro (AWD) | 2011 | Base, L | Front | All |
|
| Audi S6 | 2016–2018 | Premium Plus, Prestige | Front | All |
|
| Audi S6 | 2013–2015 | Base | Front | All |
|
| Audi S7 | 2017–2018 | Premium Plus, Prestige | Front | All |
|
| Audi S7 | 2013–2016 | Base | Front | All |
|
Specifications
As Bilstein publishes them.
- Extended Length (in)
- 20.07
- Collapsed Length (in)
- 15.44
- Extended Length (mm)
- 509.9
- Collapsed Length (mm)
- 392.2
- Upper Mount Type
- Special
- Lower Mount Type
- Base Cup
- Internal Design
- Twintube
- Finish
- Black Paint
- Boot Included
- No
- Spring Seat Included
- No
Installation & warranty
Bilstein installation instructions (PDF)
Limited Lifetime Warranty · Warranty terms (PDF)
100% genuine Bilstein, from authorized North American distribution.
BILSTEIN is a trademark of thyssenkrupp Bilstein GmbH. Eskimo is an independent retailer.
