Bilstein 25-326857 B8 8100 DSA Shock Absorber
BestB8 8100

Bilstein 25-326857 B8 8100 DSA Shock Absorber

Sold each · 2 per axle

Call (780) 473-2424

We reply to price requests within one business day.

Will it fit your vehicle?

Want it installed?Eskimo Auto Repair installs Bilstein suspension in Edmonton.
Country of origin
United States
Box
Ships in Bilstein's own box (about 76 × 20 × 14 cm, 7.1 kg)

100% genuine Bilstein, from authorized North American distribution.

Fitment

77 vehicles, newest years first

Ford F-1502024–2026King Ranch, Lariat, Platinum, STX, Tremor, XL, XLTRear4WD
  • Fits Vehicles With 0" Rear Lift
  • Without Continuously Controlled Damping
  • Not compatible with OE wheels
  • Requires wheels with maximum of 5.75" backspacing
  • Fits Vehicles With 0-1" Rear Lift
  • Without Continuously Controlled Damping
  • Not compatible with OE wheels
  • Requires wheels with maximum of 5.75" backspacing
  • Check which applies
Ford F-1502021–2023King Ranch, Lariat, Limited, Platinum, Tremor, XL, XLTRear4WD
  • Fits Vehicles With 0" Rear Lift
  • Without Continuously Controlled Damping
  • Not compatible with OE wheels
  • Requires wheels with maximum of 5.75" backspacing
  • Fits Vehicles With 0-1" Rear Lift
  • Without Continuously Controlled Damping
  • Not compatible with OE wheels
  • Requires wheels with maximum of 5.75" backspacing
  • Check which applies
Ford F-1502016–2020King Ranch, Lariat, Limited, Platinum, XL, XLTRear4WD
  • Fits Vehicles With 0-1" Rear Lift
  • Not compatible with OE wheels
  • Requires wheels with maximum of 5.75" backspacing
  • Check which applies
Ford F-1502015King Ranch, Lariat, Platinum, XL, XLTRear4WD
  • Fits Vehicles With 0-1" Rear Lift
  • Not compatible with OE wheels
  • Requires wheels with maximum of 5.75" backspacing
  • Check which applies

Specifications

As Bilstein publishes them.

Extended Length (in)
27.56
Collapsed Length (in)
16.99
Extended Length (mm)
700.0
Collapsed Length (mm)
429.0
Body Diameter (od)
2.65 in.
Piston Diameter
60mm
Shaft Diameter
18mm
Upper Mount Type
Eye 12mm
Lower Mount Type
Eye 12mm
Body Design
Smooth Body (Non-Coilover)
Internal Design
Monotube
Finish
EVO Grey
Reservoir
Yes
Adjustable Damping
Click Adjusters for High and Low Speed Compression
Boot Included
No
Spring Seat Included
No
Replacement Mounting Kit
B4-KT2-Z020A00

Installation & warranty

Bilstein installation instructions (PDF)
Limited 2-Year Warranty · Warranty terms (PDF)

100% genuine Bilstein, from authorized North American distribution.
